AW-320-24 320W 24V LED Driver (IP67 Metal)

What it’s for: the 230V-to-24V heart of a strip installation. A constant-voltage driver converts mains to the safe 24V⎓ your LED strip runs on. This AcTec unit delivers up to 320W (13.34A at 24V) of clean, analogue flicker-free power — enough for roughly 17 metres of our 14.4W/m strip with the 20% sizing headroom we recommend. Our biggest driver — commercial-scale runs and multi-zone installations from a single supply, in a rugged earthed aluminium case.

Sizing rule: add up your strip wattage (metres × W/m) and choose a driver rated at least 20% higher, so it never runs at its limit. IP67-sealed, it can live in a ceiling void, under a cabinet or outdoors.

Mains connection must be carried out by a qualified electrician. The driver comes with flying leads on both sides — 230V mains in, 24V⁠⎓ out to the strip. Hot plug-in of LEDs is not permitted.

Key features

• Analogue flicker-free output — clean, quiet light with no visible PWM
• Built-in active PFC — power factor 0.95
• IP67 sealed aluminium housing — rugged, with proper heat dissipation
• Universal 100–240V AC input
• SELV isolated output — safe extra-low voltage for strip circuits
• Protection: open circuit, short circuit, overload, over-temperature
• 6kV / 6kV surge immunity
• Flying leads both sides — earthed 3-core primary (Class I)
• CE · UKCA · TÜV certified

In the box

• 1 × AW-320-24 LED driver

Works with

• Our 24V LED strip reels
• SkyDance WiFi & RF controllers — wire between driver and strip for smart control
• Wago 221 lever connectors — for the low-voltage joints

1-year warranty.

The official AcTec datasheet — full electrical parameters, dimension drawing and wiring diagram — is attached at the bottom of this page.
